183
9RR
U.S. PATENT NO. D726,627
9 PERFORMANCE
BOLT PATTERNS:
- 4X100
- 4X98
- 5X100
- 5X108
- 5X114
- 5X112
- 5X120
- 5X98
| Part Number | Wheel Size | Bolt Circle | Offset (MM) | Back Spacing | Load Rating | Hub Bore (MM) | Finish |
|---|
| 183B-1770410035 | 17x7 | 4X100 | 35 | 5.38 | 1565 | 60.1 | Matte Black |
| 183B-177049830 | 17x7 | 4X98 | 30 | 5.18 | 1279 | 58.1 | Matte Black |
| 183B-1770510045 | 17x7 | 5X100 | 45 | 5.77 | 1565 | 75 | Matte Black |
| 183B-1770510845 | 17x7 | 5X108 | 45 | 5.77 | 1565 | 72.6 | Matte Black |
| 183B-1770545040 | 17x7 | 5X114 | 40 | 5.57 | 1565 | 72.6 | Matte Black |
| 183B-1775511245 | 17x7.5 | 5X112 | 45 | 6.02 | 1338 | 72.6 | Matte Black |
| 183B-1775512035 | 17x7.5 | 5X120 | 35 | 5.63 | 1338 | 70.1 | Matte Black |
| 183B-177559830 | 17x7.5 | 5X98 | 30 | 5.43 | 1338 | 58.1 | Matte Black |
| 183B-188049835 | 18x8 | 4X98 | 35 | 5.88 | 1279 | 58.1 | Matte Black |
| 183B-1880510045 | 18x8 | 5X100 | 45 | 6.27 | 1433 | 75 | Matte Black |
| 183B-1880511245 | 18x8 | 5X112 | 45 | | | | Matte Black |
| 183B-1880512040 | 18x8 | 5X120 | 40 | | | | Matte Black |
| 183B-1880545038 | 18x8 | 5X114 | 38 | | | | Matte Black |
| 183B-1985510045 | 19x8.5 | 5X100 | 45 | 6.52 | 1680 | 75 | Matte Black |
| 183B-1985511242 | 19x8.5 | 5X112 | 42 | | | | Matte Black |
| 183B-1985512035 | 19x8.5 | 5X120 | 35 | | | | Matte Black |
| 183B-1985545038 | 19x8.5 | 5X114 | 38 | | | | Matte Black |
| 183B-1995511242 | 19x9.5 | 5X112 | 42 | | | | Matte Black |
| 183B-1995512032 | 19x9.5 | 5X120 | 32 | | | | Matte Black |
| 183B-1995545030 | 19x9.5 | 5X114 | 30 | | | | Matte Black |
| 183B-2011511248 | 20x11 | 5X112 | 48 | | | | Matte Black |
| 183B-2011512030 | 20x11 | 5X120 | 30 | | | | Matte Black |
| 183B-2011513063 | 20x11 | 5X130 | 63 | | | | Matte Black |
| 183B-2011545058 | 20x11 | 5X114 | 58 | | | | Matte Black |
| 183B-2085510849 | 20x8.5 | 5X108 | 49 | 6.68 | 1521 | 72.6 | Matte Black |
| 183B-2085511225 | 20x8.5 | 5X112 | 25 | 5.73 | 1521 | 72.6 | Matte Black |
| 183B-2085511235 | 20x8.5 | 5X112 | 35 | 6.13 | 1521 | 72.6 | Matte Black |
| 183B-2085511242 | 20x8.5 | 5X112 | 42 | | | | Matte Black |
| 183B-2085512030 | 20x8.5 | 5X120 | 30 | 5.93 | 1521 | 70.1 | Matte Black |
| 183B-2085512048 | 20x8.5 | 5X120 | 48 | | | | Matte Black |
| 183B-2085513051 | 20x8.5 | 5X130 | 51 | | | | Matte Black |
| 183B-2085545040 | 20x8.5 | 5X114 | 40 | | | | Matte Black |
| 183B-2085545045 | 20x8.5 | 5X114 | 45 | 6.52 | 1521 | 72.6 | Matte Black |
| 183B-2090511226 | 20x9 | 5X112 | 26 | 6.02 | 1521 | 72.6 | Matte Black |
| 183B-2090511238 | 20x9 | 5X112 | 38 | 6.5 | 1521 | 72.6 | Matte Black |
| 183B-2090512030 | 20x9 | 5X120 | 30 | 6.18 | 1521 | 70.1 | Matte Black |
| 183B-2090513051 | 20x9 | 5X130 | 51 | 7.01 | 1521 | 71.6 | Matte Black |
| 183H-1880511245 | 18x8 | 5X112 | 45 | | | | Titanium |
| 183H-1880512040 | 18x8 | 5X120 | 40 | | | | Titanium |
| 183H-1880545038 | 18x8 | 5X114 | 38 | | | | Titanium |
| 183H-1985511242 | 19x8.5 | 5X112 | 42 | | | | Titanium |
| 183H-1985512035 | 19x8.5 | 5X120 | 35 | | | | Titanium |
| 183H-1985545038 | 19x8.5 | 5X114 | 38 | | | | Titanium |
| 183H-1995511242 | 19x9.5 | 5X112 | 42 | | | | Titanium |
| 183H-1995512032 | 19x9.5 | 5X120 | 32 | | | | Titanium |
| 183H-1995545030 | 19x9.5 | 5X114 | 30 | | | | Titanium |
| 183H-2011511248 | 20x11 | 5X112 | 48 | | | | Titanium |
| 183H-2011512030 | 20x11 | 5X120 | 30 | | | | Titanium |
| 183H-2011513063 | 20x11 | 5X130 | 63 | | | | Titanium |
| 183H-2011545058 | 20x11 | 5X114 | 58 | | | | Titanium |
| 183H-2085510849 | 20x8.5 | 5X108 | 49 | 6.68 | 1521 | 72.6 | Titanium |
| 183H-2085511225 | 20x8.5 | 5X112 | 25 | 5.73 | 1521 | 72.6 | Titanium |
| 183H-2085511235 | 20x8.5 | 5X112 | 35 | 6.13 | 1521 | 72.6 | Titanium |
| 183H-2085511242 | 20x8.5 | 5X112 | 42 | | | | Titanium |
| 183H-2085512030 | 20x8.5 | 5X120 | 30 | 5.93 | 1521 | 70.1 | Titanium |
| 183H-2085512048 | 20x8.5 | 5X120 | 48 | | | | Titanium |
| 183H-2085513051 | 20x8.5 | 5X130 | 51 | | | | Titanium |
| 183H-2085545040 | 20x8.5 | 5X114 | 40 | | | | Titanium |
| 183H-2085545045 | 20x8.5 | 5X114 | 45 | 6.52 | 1521 | 72.6 | Titanium |
| 183H-2090511226 | 20x9 | 5X112 | 26 | 6.02 | 1521 | 72.6 | Titanium |
| 183H-2090511238 | 20x9 | 5X112 | 38 | 6.5 | 1521 | 72.6 | Titanium |
| 183H-2090512030 | 20x9 | 5X120 | 30 | 6.18 | 1521 | 70.1 | Titanium |
| 183H-2090513051 | 20x9 | 5X130 | 51 | 7.01 | 1521 | 71.6 | Titanium |
| 183S-177049830 | 17x7 | 4X98 | 30 | 5.18 | 1279 | 58.1 | Gloss Silver |
| 183S-1775511245 | 17x7.5 | 5X112 | 45 | 6.02 | 1338 | 72.6 | Gloss Silver |
| 183S-1775512035 | 17x7.5 | 5X120 | 35 | 5.63 | 1338 | 70.1 | Gloss Silver |
| 183S-1880410035 | 18x8 | 4X100 | 35 | 5.88 | 1279 | 60.1 | Gloss Silver |
| 183S-188049835 | 18x8 | 4X98 | 35 | 5.88 | 1279 | 58.1 | Gloss Silver |
| 183S-1880510045 | 18x8 | 5X100 | 45 | 6.27 | 1433 | 75 | Gloss Silver |
| 183S-1880510845 | 18x8 | 5X108 | 45 | 6.27 | 1433 | 72.6 | Gloss Silver |
| 183S-1880511245 | 18x8 | 5X112 | 45 | | | | Gloss Silver |
| 183S-1985511242 | 19x8.5 | 5X112 | 42 | | | | Gloss Silver |
| 183S-1985545038 | 19x8.5 | 5X114 | 38 | | | | Gloss Silver |
| 183S-2085511235 | 20x8.5 | 5X112 | 35 | 6.13 | 1521 | 72.6 | Gloss Silver |
| Part Number | Wheel Size | Bolt Circle | Offset (MM) | Back Spacing | Load Rating | Hub Bore (MM) | Finish |
|---|
| 183B-1770410035 | 17x7 | 4X100 | 35 | 5.38 | 1565 | 60.1 | Matte Black |
| 183B-177049830 | 17x7 | 4X98 | 30 | 5.18 | 1279 | 58.1 | Matte Black |
| 183B-1770510045 | 17x7 | 5X100 | 45 | 5.77 | 1565 | 75 | Matte Black |
| 183B-1770510845 | 17x7 | 5X108 | 45 | 5.77 | 1565 | 72.6 | Matte Black |
| 183B-1770545040 | 17x7 | 5X114 | 40 | 5.57 | 1565 | 72.6 | Matte Black |
| 183S-177049830 | 17x7 | 4X98 | 30 | 5.18 | 1279 | 58.1 | Gloss Silver |
| 183B-1775511245 | 17x7.5 | 5X112 | 45 | 6.02 | 1338 | 72.6 | Matte Black |
| 183B-1775512035 | 17x7.5 | 5X120 | 35 | 5.63 | 1338 | 70.1 | Matte Black |
| 183B-177559830 | 17x7.5 | 5X98 | 30 | 5.43 | 1338 | 58.1 | Matte Black |
| 183S-1775511245 | 17x7.5 | 5X112 | 45 | 6.02 | 1338 | 72.6 | Gloss Silver |
| 183S-1775512035 | 17x7.5 | 5X120 | 35 | 5.63 | 1338 | 70.1 | Gloss Silver |
| Part Number | Wheel Size | Bolt Circle | Offset (MM) | Back Spacing | Load Rating | Hub Bore (MM) | Finish |
|---|
| 183B-188049835 | 18x8 | 4X98 | 35 | 5.88 | 1279 | 58.1 | Matte Black |
| 183B-1880510045 | 18x8 | 5X100 | 45 | 6.27 | 1433 | 75 | Matte Black |
| 183B-1880511245 | 18x8 | 5X112 | 45 | | | | Matte Black |
| 183B-1880512040 | 18x8 | 5X120 | 40 | | | | Matte Black |
| 183B-1880545038 | 18x8 | 5X114 | 38 | | | | Matte Black |
| 183H-1880511245 | 18x8 | 5X112 | 45 | | | | Titanium |
| 183H-1880512040 | 18x8 | 5X120 | 40 | | | | Titanium |
| 183H-1880545038 | 18x8 | 5X114 | 38 | | | | Titanium |
| 183S-1880410035 | 18x8 | 4X100 | 35 | 5.88 | 1279 | 60.1 | Gloss Silver |
| 183S-188049835 | 18x8 | 4X98 | 35 | 5.88 | 1279 | 58.1 | Gloss Silver |
| 183S-1880510045 | 18x8 | 5X100 | 45 | 6.27 | 1433 | 75 | Gloss Silver |
| 183S-1880510845 | 18x8 | 5X108 | 45 | 6.27 | 1433 | 72.6 | Gloss Silver |
| 183S-1880511245 | 18x8 | 5X112 | 45 | | | | Gloss Silver |
| Part Number | Wheel Size | Bolt Circle | Offset (MM) | Back Spacing | Load Rating | Hub Bore (MM) | Finish |
|---|
| 183B-1985510045 | 19x8.5 | 5X100 | 45 | 6.52 | 1680 | 75 | Matte Black |
| 183B-1985511242 | 19x8.5 | 5X112 | 42 | | | | Matte Black |
| 183B-1985512035 | 19x8.5 | 5X120 | 35 | | | | Matte Black |
| 183B-1985545038 | 19x8.5 | 5X114 | 38 | | | | Matte Black |
| 183H-1985511242 | 19x8.5 | 5X112 | 42 | | | | Titanium |
| 183H-1985512035 | 19x8.5 | 5X120 | 35 | | | | Titanium |
| 183H-1985545038 | 19x8.5 | 5X114 | 38 | | | | Titanium |
| 183S-1985511242 | 19x8.5 | 5X112 | 42 | | | | Gloss Silver |
| 183S-1985545038 | 19x8.5 | 5X114 | 38 | | | | Gloss Silver |
| 183B-1995511242 | 19x9.5 | 5X112 | 42 | | | | Matte Black |
| 183B-1995512032 | 19x9.5 | 5X120 | 32 | | | | Matte Black |
| 183B-1995545030 | 19x9.5 | 5X114 | 30 | | | | Matte Black |
| 183H-1995511242 | 19x9.5 | 5X112 | 42 | | | | Titanium |
| 183H-1995512032 | 19x9.5 | 5X120 | 32 | | | | Titanium |
| 183H-1995545030 | 19x9.5 | 5X114 | 30 | | | | Titanium |
| Part Number | Wheel Size | Bolt Circle | Offset (MM) | Back Spacing | Load Rating | Hub Bore (MM) | Finish |
|---|
| 183B-2011511248 | 20x11 | 5X112 | 48 | | | | Matte Black |
| 183B-2011512030 | 20x11 | 5X120 | 30 | | | | Matte Black |
| 183B-2011513063 | 20x11 | 5X130 | 63 | | | | Matte Black |
| 183B-2011545058 | 20x11 | 5X114 | 58 | | | | Matte Black |
| 183H-2011511248 | 20x11 | 5X112 | 48 | | | | Titanium |
| 183H-2011512030 | 20x11 | 5X120 | 30 | | | | Titanium |
| 183H-2011513063 | 20x11 | 5X130 | 63 | | | | Titanium |
| 183H-2011545058 | 20x11 | 5X114 | 58 | | | | Titanium |
| 183B-2085510849 | 20x8.5 | 5X108 | 49 | 6.68 | 1521 | 72.6 | Matte Black |
| 183B-2085511225 | 20x8.5 | 5X112 | 25 | 5.73 | 1521 | 72.6 | Matte Black |
| 183B-2085511235 | 20x8.5 | 5X112 | 35 | 6.13 | 1521 | 72.6 | Matte Black |
| 183B-2085511242 | 20x8.5 | 5X112 | 42 | | | | Matte Black |
| 183B-2085512030 | 20x8.5 | 5X120 | 30 | 5.93 | 1521 | 70.1 | Matte Black |
| 183B-2085512048 | 20x8.5 | 5X120 | 48 | | | | Matte Black |
| 183B-2085513051 | 20x8.5 | 5X130 | 51 | | | | Matte Black |
| 183B-2085545040 | 20x8.5 | 5X114 | 40 | | | | Matte Black |
| 183B-2085545045 | 20x8.5 | 5X114 | 45 | 6.52 | 1521 | 72.6 | Matte Black |
| 183H-2085510849 | 20x8.5 | 5X108 | 49 | 6.68 | 1521 | 72.6 | Titanium |
| 183H-2085511225 | 20x8.5 | 5X112 | 25 | 5.73 | 1521 | 72.6 | Titanium |
| 183H-2085511235 | 20x8.5 | 5X112 | 35 | 6.13 | 1521 | 72.6 | Titanium |
| 183H-2085511242 | 20x8.5 | 5X112 | 42 | | | | Titanium |
| 183H-2085512030 | 20x8.5 | 5X120 | 30 | 5.93 | 1521 | 70.1 | Titanium |
| 183H-2085512048 | 20x8.5 | 5X120 | 48 | | | | Titanium |
| 183H-2085513051 | 20x8.5 | 5X130 | 51 | | | | Titanium |
| 183H-2085545040 | 20x8.5 | 5X114 | 40 | | | | Titanium |
| 183H-2085545045 | 20x8.5 | 5X114 | 45 | 6.52 | 1521 | 72.6 | Titanium |
| 183S-2085511235 | 20x8.5 | 5X112 | 35 | 6.13 | 1521 | 72.6 | Gloss Silver |
| 183B-2090511226 | 20x9 | 5X112 | 26 | 6.02 | 1521 | 72.6 | Matte Black |
| 183B-2090511238 | 20x9 | 5X112 | 38 | 6.5 | 1521 | 72.6 | Matte Black |
| 183B-2090512030 | 20x9 | 5X120 | 30 | 6.18 | 1521 | 70.1 | Matte Black |
| 183B-2090513051 | 20x9 | 5X130 | 51 | 7.01 | 1521 | 71.6 | Matte Black |
| 183H-2090511226 | 20x9 | 5X112 | 26 | 6.02 | 1521 | 72.6 | Titanium |
| 183H-2090511238 | 20x9 | 5X112 | 38 | 6.5 | 1521 | 72.6 | Titanium |
| 183H-2090512030 | 20x9 | 5X120 | 30 | 6.18 | 1521 | 70.1 | Titanium |
| 183H-2090513051 | 20x9 | 5X130 | 51 | 7.01 | 1521 | 71.6 | Titanium |
